YOKOGAWA F3CU04-0S User Manual

E1-7
IM 34M06H62-02E 2nd Edition : June 2008-00
Table E1.9 Operation Parameters (3/3)
Data Position Number
Symbol Description Attribute Stored See Also
Loop 1 Loop 2 Loop 3 Loop 4
241 441 641 841 3.SP Set point RW Irregular
B2.4
C4.1
242 442 642 842 3.A1 Alarm 1 preset value RW 
C8.1
243 443 643 843 3.A2 Alarm 2 preset value RW 
244 444 644 844 3.A3 Alarm 3 preset value RW 
245 445 645 845 3.A4 Alarm 4 preset value RW 
246 446 646 846 3.PB Proportional band RW  C6.2
247 447 647 847 3.TI Integral time RW  C6.3
248 448 648 848 3.TD Derivative time RW  C6.4
249 449 649 849 3.OH Upper output limit RW 
C2.4.2
250 450 650 850 3.OL Lower output limit RW 
251 451 651 851 3.MR Manual reset value RW  C6.3
252 452 652 852 3.HYS ON/OFF control hysteresis RW  C2.4.1
253 453 653 853 3.DR Forward/reverse switch RW  C6.1
254 454 654 854 3.GAIN.C Cooling gain RW  C2.4.3
255 455 655 855 3.HYS.C Cooling ON/OFF control hysteresis RW  C2.4.4
256 456 656 856 3.DB Dead band RW 
C2.4.3
C2.4.4
257 457 657 857 3.POUT Preset output RW 
C7.1
258 458 658 858 3.POUT.C Cooling preset output RW 
259 459 659 859
Not used
260 460 660 860
261 461 661 861 4.SP Set point RW Irregular
B2.4
C4.1
262 462 662 862 4.A1 Alarm 1 preset value RW 
C8.1
263 463 663 863 4.A2 Alarm 2 preset value RW 
264 464 664 864 4.A3 Alarm 3 preset value RW 
265 465 665 865 4.A4 Alarm 4 preset value RW 
266 466 666 866 4.PB Proportional band RW  C6.2
267 467 667 867 4.TI Integral time RW  C6.3
268 468 668 868 4.TD Derivative time RW  C6.4
269 469 669 869 4.OH Upper output limit RW 
C2.4.2
270 470 670 870 4.OL Lower output limit RW 
271 471 671 871 4.MR Manual reset value RW  C6.3
272 472 672 872 4.HYS ON/OFF control hysteresis RW  C2.4.1
273 473 673 873 4.DR Forward/reverse switch RW  C6.1
274 474 674 874 4.GAIN.C Cooling gain RW  C2.4.3
275 475 675 875 4.HYS.C Cooling ON/OFF control hysteresis RW  C2.4.4
276 476 676 876 4.DB Dead band RW 
C2.4.3
C2.4.4
277 477 677 877 4.POUT Preset output RW 
C7.1
278 478 678 878 4.POUT.C Cooling preset output RW 
279 479 679 879
Not used
280 480 680 880
Irregular: You need to execute a specific procedure every time to update stored set point values.
