E1-8
IM 34M06H62-02E 2nd Edition : June 2008-00
Table E1.10 Alarm-related Settings
Data Position Number
Symbol Description Attribute Stored
See
Also
Loop 1 Loop 2 Loop 3 Loop 4
281 481 681 881 AL1 Alarm 1 type RW 
C8.1
282 482 682 882 AL2 Alarm 2 type RW 
283 483 683 883 AL3 Alarm 3 type RW 
284 484 684 884 AL4 Alarm 4 type RW 
285 485 685 885 HY1 Alarm 1 hysteresis RW 
C8.1
286 486 686 886 HY2 Alarm 2 hysteresis RW 
287 487 687 887 HY3 Alarm 3 hysteresis RW 
288 488 688 888 HY4 Alarm 4 hysteresis RW 
289 489 689 889 DLY1 Alarm 1 ON delay RW 
C8.3
290 490 690 890 DLY2 Alarm 2 ON delay RW 
291 491 691 891 DLY3 Alarm 3 ON delay RW 
292 492 692 892 DLY4 Alarm 4 ON delay RW 
293 493 693 893
Not used 294 494 694 894
295 495 695 895
