YOKOGAWA GC8000 - CSA Specification Wiring; ATEX;IECEx;NEPSI Wiring; TIIS Specification Wiring

18
TI 11B08A01-01E
CAUTION
• Theunusedelectricalconnectionportsshouldbeclosedwithanappropriateameproof-
certiedplug.
• Analyzers have pressurized enclosures. The cable end should be sealed in order to
maintain pressure to the pressurized enclosure. Otherwise, power is not supplied to the
electronics section.
<ATEX, IECEx, NEPSI>
WARNING
• AllwiringshallcomplywithLocalElectricCodesandRequirements.
• Inahazardousarea,useappropriateameproof-certiedpartsforconnectingcables.
• Allexternallypoweredinputsignalsintothepressurizedenclosureshallbeisolatedby
external relays controlled by the Ex px protection system(Ex px safety device).
CAUTION
• Theunusedelectricalconnectionportsshouldbeclosedwithanappropriateameproof-
certiedplug.
• Analyzershavepressurizedenclosures.Thecableendshouldbesealedinorderto
maintain pressure to the pressurized enclosure. Otherwise, power is not supplied to the
electronics section.
<TIIS>
WARNING
• IncaseofTIIS-certiedwiring,theattachedcablepackingadaptersorsealingttingmust
be used.
Otherwise, it does not comply with TIIS regulation.
• Usethewiringtothepressurizedenclosure,whoseallowabletemperatureismorethan
80°C.
IMPORTANT
Cables should be arranged in an orderly manner in the protection system.
Otherwise, they may damage other parts (e.g. relay).
Sep. 07, 2017-00
