YOKOGAWA GC8000 User Manual

2. Installation, Piping, and Wiring
84
TI 11B08A01-01E
n Ethernet(opticalber)(N)
CAUTION
(N)cable:
Requiredmaximumallowabletemperatureofthecablesdependsonthetemperatureclass
of the instrument and the actual ambient temperature. Use cables with maximum allowable
temperature shown in the table below.
Temperature Class T1, T2 T3 T4
Maximum allowable
temperature of cable
Ambient temp.
Up to 30°C Up to 35°C Up to 40°C 60°C
31 to 36°C 36 to 40°C 41 to 45°C 65°C
37 to 43°C 41 to 45°C 46 to 50°C 70°C
44 to 50°C 46 to 50°C 75°C
ConnectanopticalbertothemediaconvertershowninFigure2.26.
Ethernet
T
x
R
x
T
x
R
x
(N)
(N)
T
x
R
x
T
x
R
x
CPU board
Media converter
For dual
Media converter for SC fiber-optics
/RJ-45 twisted pair
(if needed)
example:
MOXA made P/N: IMC-101-M-SC
Figure2.26 Ethernet(opticalber)
