1. Overview
39
TI 11B08A01-01E
Desk-top type
• ConverterforRS-422/RS-232C:K9806AT
• SignalinterrupterforEthernettwistedpaircable:K9806AB
135
90
15
38
41.5
Unit: mm
The number and the location of
the terminals depend on its part number.
Weight: approx. 500 g
Note: Desk-top type should be installed horizontally.
Sep. 07, 2017-00
