YOKOGAWA SMARTDAC+ GP10 User Manual

1-81
IM 04L51B01-01EN
Configuring the GX/GP
1
2
3
4
5
App
Index
1.7 Setting Display Conditions
Set the display conditions.
1.7.1 Setting the Trend Interval
Path
GX/GP: MENU key > Browse tab > Setting > Setting menu Display settings > Trend
interval
Web application: Config. tab > Display settings > Trend interval
Hardware configurator: Display settings > Trend interval
Description
Setup Item Selectable Range or Options Default Value
Trend interval [/div] (recording
interval)
1
5s (100ms),
2, 3
10s (200ms),
2, 3
15s (500ms),
2
30s (1s), 1min (2s), 2min (4s), 5min (10s),
10min (20s), 15min (30s), 20min (40s), 30min
(1min), 1h (2min), 2h (4min), 4h (8min), 10h
(20min)
1min (2s)
Trend rate switching Off, On Off
Second interval [/div] (recording
interval)
1
5s (100ms),
2
10s (200ms),
2
15s (500ms),
2
30s (1s), 1min (2s), 2min (4s), 5min (10s),
10min(20s), 15min (30s), 20min (40s), 30min
(1min), 1h(2min), 2h (4min), 4h (8min), 10h
(20min)
1min (2s)
1 Does not appear if the recording mode is set to Event in basic settings under recording settings
Appears when trend rate switching is set to On.
2 Cannot be specified if an electromagnetic relay type (type suffix code -T1) analog input module
is in use (configured).
3 Cannot be specified if a low withstand voltage relay type (type suffix code -L1) analog input
module is in use (configured).
Trend interval [/div]
Set the trend interval.
RelationshipbetweentheScanIntervalandTrendInterval
The shortest trend interval that you can specify varies depending on the scan interval.
Scan Interval Shortest Trend Interval
100 ms 5 s
200 ms 10 s
500 ms 15 s
1 s 30 s
2 s 1 min
5 s 5 min
Trendrateswitching
Set this to On to enable the function that switches the trend interval while the recording is in
progress.
During data acquisition, you can switch from the normal trend interval to the secondary trend
interval. You can also switch back to the normal trend interval.
Note
Only the displayed time axis changes when you switch to the secondary trend interval. The trend
interval of recording data does not change.
Second interval [/div]
Set the time per division for the secondary interval. You cannot choose a secondary interval
that is shorter than the scan interval.
