YOKOGAWA SMARTDAC+ GP10 User Manual

1-50
IM 04L51B01-01EN
Logging
Set this On to display an alarm (notify you) when an alarm occurs. If set to Off, when an
alarm occurs, the GM outputs signals to alarm output DO channels or internal switches but
does not display the alarm. Alarms are also not recorded in the alarm summary.
Output type
Set the alarm output destination.
Output No.
Set the number of the DO channel or internal switch to output alarms to.
Alarmdelay(fordelayhigh/lowlimitalarms)
Setup Item Selectable Range or Options Default Value
Hour 1 to 24 0
Minute 0 to 59 0
Second 0 to 59 10
Hour, Minute, and Second
Set the alarm delay. These values are valid when the delay high limit or delay low limit is in
use.
1.4.3 Setting the Display
Path
GX/GP: MENU key > Browse tab > Setting > Setting menu Pulse input channel settings
> Display settings
Web application: Config. tab > Pulse input channel settings > Channel range (display
example: 0701-0710) > Display settings
Hardware configurator: Pulse input channel settings > Channel range (display example:
0701-0710) > Display settings
Description
Setup Item Selectable Range or Options Default Value
First-CH Pulse input channel —
Last-CH Pulse input channel —
First-CH, Last-CH
Set the target channels. The channels that you can specify appear depending on the module
configuration.
Tag
Setup Item Selectable Range or Options Default Value
Characters
Character string (up to 32 characters,
A
a
#
1
)
—
No.
Character string (up to 16 characters,
A
a
#
1
)
—
Characters
Set the tag.
Not all characters may be displayed due to space constraints.
No.
Set the tag number.
1.4ConfiguringPulseInputChannels(Releasenumber3andlater)
