1-143
IM 04L51B01-01EN
Configuring the GX/GP
1
1.17 ConfiguringtheEthernetCommunication
Function
Set the Ethernet communication conditions.
For the WT connection client settings (WT communication (/E2 option)), see the WT
Communication (/E2) User’s Manual (IM 04L51B-19EN).
For the SLMP client settings (SLMP communication (/E4 option)), see the SLMP
Communication (/E4) User’s Manual (IM 04L51B-21EN).
1.17.1 Setting Basic Communication Conditions
Path
GX/GP: MENU key > Browse tab > Setting > Setting menu Communication(Ethernet)
settings > Basic settings
Web application: Config. tab > Communication(Ethernet)settings > Communication
(Ethernet)Basicsettings
Hardware configurator: Communication(Ethernet)settings > Ethernetbasicsettings
Description
Automatic IP settings
Setup Item Selectable Range or Options Default Value
Obtain IP address
automatically
Off, On Off
Obtain IP address automatically
Set this to On to automatically obtain the IP address (DHCP).
IP Address
1
Setup Item Selectable Range or Options Default Value
IP address 0.0.0.0 to 255.255.255.255 0.0.0.0
Subnet mask 0.0.0.0 to 255.255.255.255 0.0.0.0
Default gateway 0.0.0.0 to 255.255.255.255 0.0.0.0
1 Appears when Obtain IP address automatically is set to Off.
IP Address
Set a fixed IP address to assign to the GX/GP.
Subnet mask
Set the subnet mask. Set this in accordance with the system or network that the GX/GP
belongs to.
Defaultgateway
Set the IP address of the default gateway.
Automatic DNS settings
1
Setup Item Selectable Range or Options Default Value
Obtain DNS address automatically Off, On Off
1 Appears when Obtain IP address automatically is set to On.
Obtain DNS address automatically
Set this to On to automatically obtain the DNS server address. Otherwise, set this to Off.
If you set this to Off, you need to set the primary and secondary DNS servers and domain
suffixes.
To Next Page
