1-82
IM 04L51B01-01EN
Explanation
If the recording mode is set to Event and trend rate switching (Second interval) is set to Off,
the trend interval depends on the recording interval of event data. If trend rate switching
(Second interval) is set to On, you can specify any trend interval you want. However, the
minimum trend interval that you can set depends on the scan interval.
RecordingIntervalofEventDataandTrend Interval
Recording interval 100ms 200ms 500ms 1s 2s 5s 10s
Trend interval [/div] 5s 10s 15s 30s 1min 150s 5min
Recording interval 15s 20s 30s 1min 2min 5min 10min
Trend interval [/div] 450s 10min 15min 30min 1h 150min 5h
Recording interval 15min 20min 30min
Trend interval [/div] 450min 10h 15h
1.7.2 Setting Display Groups
Assign channels and set the group name for each display group. Set lines at specified
positions in the waveform display range on the Trend display. Set to display a scale with a
scale image.
If the multi-batch function (/BT option) is enabled, see the multi-batch function manual (IM
04L51B01-03EN).
Path
GX/GP: MENU key > Browse tab > Setting > Setting menu Display settings > Group
settings
Web application: Config. tab > Display settings > Group settings > GroupNo.(display
example:1-20)
Hardware configurator: Display settings > Group settings > GroupNo.(display
example:1-20)
Description
Setup Item Selectable Range or Options Default Value
Group number GX20-1/GP20-1: 1 to 50
GX20-2/GP20-2: 1 to 60
GX10/GP10: 1 to 30
1
Group number
Select the target group number.
Group settings
Setup Item Selectable Range or Options Default Value
On/Off Off, On Off
Group name
Character string (up to 16 characters,
A
a
#
1
)
—
Channel set GX20/GP20: Up to 20
GX10/GP10: Up to 10
—
On/Off
Set this to On to use the target group number.
Group name
Set the group name.
Channel set
Select from AI channels, DI channels, DO channels, math channels (/MT option), and
communication channels (/MC option).
1.7 Setting Display Conditions
