YOKOGAWA SMARTDAC+ GP10 User Manual

4-57
IM 04L51B01-01EN
Using Modbus Functions (Communicating with Modbus devices)
1
2
3
4
5
App
Index
Type I/O Channel Data Register Read/Write Data
Type
I/O Channel status information Channel 0701 data 00851 R Bit string
| |
Channel 0750 data 00900
Channel 0801 data 00901
| |
Channel 0850 data 00950
Channel 0901 data 00951
| |
Channel 0950 data 01000
Communication Channel Data
Type Communication Channel
Data
Register Read/Write Data Type
Communication channnel data Channel C001 data 01001 R/W Bit string
| |
Channel C300 data 01300
Communication channel status
information
Channel C001 data 01501 R
| |
Channel C300 data 01800
InternalSwitchData
Type InternalSwitchdata Register Read/Write Data Type
Internal switch data Channel S001 data 02001 R/W Bit string
| |
Channel S100 data 02100
4.5.7 Input Relay
Input relay registers can only be accessed from the GX/GP channels.
The input relay area is both readable and writable. The registers contain 1-bit data.
The registers take on the value of 0 when the data is 0 and the value of 1 otherwise to
indicate the data or status.
I/O Channel Data
Type I/O Channel Data Register Read/Write Data Type
I/O Channel Data Channel 0001 data 10001 R Bit string
| |
Channel 0050 data 10050
Channel 0101 data 10051
| |
Channel 0150 data 10100
Channel 0201 data 10101
| |
Channel 0250 data 10150
Channel 0301 data 10151
| |
Channel 0350 data 10200
Channel 0401 data 10201
| |
Channel 0450 data 10250
Channel 0501 data 10251
| |
Channel 0550 data 10300
Channel 0601 data 10301
| |
Channel 0650 data 10350
Channel 0701 data 10351
| |
Channel 0750 data 10400
Continued on next page
4.5 Modbus Function and Register Assignments
