3-13
IM 04L51B01-01EN
Using Network Functions (Ethernet interface)
3
Saving Display Data
Follow the procedure below to save unsaved display data stored in the internal memory to
the SD memory card.
Procedure
1
On the Operation tab, click Display save.
A Display save dialog box appears.
2
Click Save display data.
The display data is saved.
Resetting a Relative Timer
Follow the procedure below to reset and start a relative timer.
Procedure
1
On the Operation tab, click Timer reset.
The Timer reset dialog box appears.
2
Click the timer you want to reset, and click Reset.
The timer is reset.
Resetting a Match Time Timer
Follow the procedure below to reset a timer that has expired.
Procedure
1
On the Operation tab, click Reset Match Time Timer.
The Match time timer reset dialog box appears.
2
Click the match time timer you want to reset, and click Reset.
The match time timer is reset.
Changing the batch number, lot number, and batch comment
Follow the procedure below to change the batch number, lot number, and batch comment.
When the GX/GP is recording, you can enter only batch comments that have not been
entered yet.
Procedure
1
On the Operation tab, click Batch.
The Batch box appears.
2
Enter the batch number, lot number, and batch comment, and click Change.
The batch number, lot number, and batch comment are changed.
For the procedure to enter the batch number, lot number, and batch comment, see
page 1-112 in section 1.11, “Configuring the Batch Function”
To delete a batch comment, enter a space.
3.1 Using the Web Application to Change the GX/GP Settings, Monitor Data, and Control the GX/GP (Web server function)
To Next Page
