YOKOGAWA SMARTDAC+ GP10 User Manual

1-37
IM 04L51B01-01EN
Configuring the GX/GP
1
2
3
4
5
App
Index
ExecutionoftheInputMeasurement(Releasenumber2andlater)
The linearizer input value is set to the current measured value.
1to12(Whenthemodeissettocorrectionfactor)(onlyforthe/
AHoption)
*
Setup Item Selectable Range or Options Default
Value
Uncorrected value -999999 to 999999 —
Instrument correction factor -999999 to 999999 —
Sensor correction factor -999999 to 999999 —
Execution of the input measurement — —
* The number of displayed points varies depending on the number of set points.
Uncorrected value
Enter the uncorrected value. Set a value that is greater than the previous value.
• Channels using linear scaling or square root computation
–999999 to 999999 (the decimal place is the same as that for the scale value)
• Other channels
Values inside parentheses are examples for the 2 V range.
Measurable range (–2.0000 to 2.0000 V)
Instrument correction factor
Set the instrument-dependent correction factor.
• Channels using linear scaling
–999999 to 999999 (the decimal place is the same as that for the scale value)
However, the sum of this factor with the sensor correction factor must not exceed this
range.
Example:
If the instrument correction factor 12 is set to 999999, the selectable range for sensor
correction factor 12 is –999999 to 0.
• Other channels
Values inside parentheses are examples for the 2 V range.
Measurement span width ± 100% (–4.0000 to 4.0000 V)
However, the sum of this factor with the sensor correction factor must not exceed this
range.
Sensor correction factor
Set the sensor-dependent correction factor.
• Channels using linear scaling
–999999 to 999999 (the decimal place is the same as that for the scale value)
However, the sum of this factor with the instrument correction factor must not exceed this
range.
• Other channels
Values inside parentheses are examples for the 2 V range.
Measurement span width ± 100% (–4.0000 to 4.0000 V)
However, the sum of this factor with the instrument correction factor must not exceed this
range.
ExecutionoftheInputMeasurement(Releasenumber3andlater)
The uncorrected value is set to the current measured value.
1.2ConfiguringAIChannels(Analog(includingDI)input)channelsandAI(mA)channels
