1-45
IM 04L51B01-01EN
Configuring the GX/GP
1
2
3
4
5
App
Index
Scale
Setup Item Selectable Range or Options Default Value
Position GX20, GP20: Off, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10
GX10, GP10: Off, 1, 2, 3, 4, 5, 6
1
Division
1
4, 5, 6, 7, 8, 9, 10, 11, 12, C10 10
1 Appears when the Rage Type is set to Pulse.
Position
Set this to set the scale display position of the trend display. Set this to Off to not display
scales.
Division
Set the number of divisions to make with the main scale marks.
C10: The scale is equally divided into 10 sections by main scale marks, and scale values are
indicated at 0, 30, 50, 70, and 100% positions.
For display examples, see the scale settings on page 1-23 in section 1.2.3, “Setting the
Display”.
Bar graph
Setup Item Selectable Range or Options Default Value
Base position Lower, Center, Upper Lower
Division
1
4, 5, 6, 7, 8, 9, 10, 11, 12 10
1 Appears when the Rage Type is set to Pulse.
Base position
Set the bar graph base position. This setting is applied on the bar graph display and when
you are displaying the current value on the scale as a bar graph on the trend displays.
Division
Set the number of divisions to make with the main scale marks.
For display examples, see the bar graph settings on page 1-23 in section 1.2.3, “Setting the
Display”.
Alarm point mark
Setup Item Selectable Range or Options Default Value
Indicate on Scale Off, On On
Mark kind Alarm, Fixed Alarm
Alarm 1 color to Alarm 4 color
1
24 colors (red, green, blue, blue violet, brown,
orange, yellow-green, light blue, violet, gray,
lime, cyan, dark blue, yellow, light gray, purple,
black, pink, light brown, light green, dark gray,
olive, dark cyan, and spring green) and a user-
defined color (1 color)
—
1 Appears when the Mark kind is set to Fixed.
Indicate on Scale
Set this to On to display alarm point marks on the scale. Set this to Off to not display them.
This setting is shared with the bar graph display.
Mark kind
Options Description Mark Shape
Alarm Displayed normally in green. Displayed in the specified color
when an alarm occurs.
or
Fixed Displayed with a fixed color.
Alarm 1 color to Alarm 4 color
When Mark kind is set to Fixed, set the display colors of point marks for alarm levels 1 to 4.
1.3ConfiguringDIChannels(Digitalinputchannels)
