JOHNSON CONTROLS

SECTION 2 - START-UP AND OPERATION

FORM 102.20-OM2

ISSUE DATE: 6/01/2015

TOP VIEW OF UNIT

POSITIVE PRESSURE / AIR BLOWN THROUGH HEATER

NEGATIVE PRESSURE / AIR DRAWN THROUGH HEATER

BLOWER

HEATER

AIRFLOW

PICK UP TU BE TOWARDS BLOWER

ATTACHED TO HIGH PORT OF AIRFLOW SWITCH

PICK UP TUBE TOWARDS BLOWER

ATTACHED TO LOW PORT OF AIRFLOW SWITCH

AIRFLOW

FIGURE 38 - PRESSURE PROBE DIRECTION

LD14268

HIGH PORT

LOW PORT

MOUNTING

BRACKET

FIGURE 39 - AIR FLOW SWITCH CONNECTIONS

LD14270
