Getting Started
24
Figure 14 CC6000 Mounting Bracket - Portrait Orientation
Figure 15 CC6000 Mounting Bracket (KT-152098-03) - Landscape Orientation
Shoulder Screw Hole (4)
Power Supply
Wall Screw Hole (4)
Shoulder Screw Hole (4)
Wall Screw Hole (4)
Securing Screw
Securing
Screw Hole
Power Supply
