Zebra LS2208 Reference Guide

Maintenance and Technical Specifications 3 - 7
The signal descriptions in Table 3-3 apply to the connector on the scanner and are for reference only.
Table 3-3 Scanner Signal Pin-outs
LS2208
Pin IBM Synapse RS-232
Keyboard
Wedge
Wand USB
Scanner
Emulation
1 Reserved SynClock Reserved Reserved Reserved Jump to Pin 6 DBP
2 Power Power Power Power Power Power Power
3 Ground Ground Ground Ground Ground Ground Ground
4 IBM_A(+) Reserved TxD KeyClock DBP Reserved SOS
5 Reserved Reserved RxD TermData CTS D + Decode
6 IBM_B(-) SynData RTS KeyData RTS Jump to Pin 1 Trigger
7 Reserved Reserved CTS TermClock Reserved D - Enable
8 Reserved Reserved Reserved Reserved Reserved Reserved Reserved
9 Reserved Reserved Reserved Reserved Reserved Reserved Reserved
10 Reserved Reserved Reserved Reserved Reserved Reserved Reserved
NOTE Wand is only supported with the LS2208-SR20541R and LS2208-SR20547R configurations.

Zebra LS2208 Specifications

General

Scan Technology	Laser
Connectivity	Wired
Scan Pattern	Single line
Drop Specification	Withstands multiple 5 ft./1.5 m drops to concrete
Scanner Type	Handheld
Scan Rate	100 scans per second
Humidity	5% to 95% (non-condensing)
Interface Options	USB, RS-232, Keyboard Wedge
Decode Capability	1D barcodes
Dimensions	15.2 cm H x 6.3 cm W x 8.4 cm D
Weight	146 g
Operating Temperature	0°C to 50°C
Resolution	5 mil
Supported Barcodes	UPC/EAN, Code 39, Code 128, GS1 DataBar
Storage Temperature	-40°C to 70°C
