OPERATION
ZEISS Operating and function controls - description Axio Observer
84 431004-7244-001 12/2016
5.2 Operating and function controls - description
On / off switch (Fig. 57/1) or standby button (Fig. 58/1)
− When the microscope is on, the power LED on the front of the stand lights up (see also section 4.19)
Left sideport (Fig. 57/2)
− Port for connecting documentation equipment
− Various splitting ratios for left sideport and visual observation (vis), depending on instrument
configuration
Manual (Fig. 57/3) or motorized focusing drive (Fig. 59/3), left side
− Coarse focusing drive approx. 2 mm/revolution and fine focusing drive approx. 1/10 of coarse/fine
focus transmission ratio
− Total travel approx. 10 mm, 13 mm also possible
− Coarse adjustment (large knob), fine adjustment (small knob or disk)
− Optional: fine drive, flat right or left, 5, 5 materials stand always flat (already included in stand)
Light path selector wheel (left / right sideport / vis) (Fig. 57/4)
− Selects beam splitting for right sideport (doc), left sideport (doc) and visual (vis) observation
(3, 3 materials stand: left sideport / vis only)
− 2 or 3 switch positions with various beam splitting ratios
− Instrument configuration with sideport 60N left (L 80); 2 switch positions (425150-0000-000):
100 % vis: 0 % doc
20 % vis : 80 % doc left
− Instrument configuration with sideport 60N left (L 100); 2 switch positions (425151-0000-000):
100 % vis: 0 % doc left
0 % vis : 100 % doc left
− Instrument configuration with sideport 60N left (L 100, L 50); 3 switch positions (425152-0000-000):
100 % vis: 0 % doc
0 % vis : 100 % doc left
50 % vis : 50 % doc left
− Instrument configuration with sideport 60N right (R 100, R 50); 3 switch positions (425153-0000-
000):
100 % vis: 0 % doc
0 % vis : 100 % doc right
50 % vis : 50 % doc right
− Instrument configuration with sideport 60N left (L 100) and right (R 80); 3 switch positions (425154-
0000-000):
100 % vis: 0 % doc
0 % vis :100 % doc left
20 % vis : 80 % doc right
