OPERATION
ZEISS TFT display touchscreen on the Axio Observer 7, 7 materials Axio Observer
116 431004-7244-001 12/2016
5.11.2 Menu overview
The menu overview shown below may differ from the available menus for your microscope
configuration. It represents all possible menu options including optional components and menu
items which are accessible only if the user has administrator privileges. (Any user not logged in
as an administrator has only read privileges).
The Microscope -> Control page has different tabs depending on the stand type (Bio / Med
or MAT) set under Settings -> User -> Stand type (see page 140). The menu overview below
shows both versions.
The first level buttons shown on the extreme left are displayed on the navigation bar (Fig. 94). Press
Microscope, Settings or Display to change the buttons displayed on the navigation bar.
The buttons on the second level of the navigation bar call up the corresponding tabs. Touching the tabs
causes the corresponding buttons to be displayed on the controls area.
All operating functions are exclusively displayed in the Controls area (third level) (see page 114) or in a
Pop-up windows (see page 115). They are not displayed in the status bar.
