Zenith L30W36 - External Control Device Setup

44
- Connect the RS-232C input jack to a PC and control the Monitor’s functions (such as ON/OFF,
INPUT SELECT, MUTE) externally.
YPB PR
R
L
MONO
AUDIO
VIDEO
S-VIDEO
AV INPUT
COMPONENT
(DVD/DTV INPUT)
AC INPUT
R
L
AUDIO
RGB 2 INPUT
(DIGITAL RGB INPUT)
RGB 1 INPUT
(PC/DTV INPUT)
RS 232C INPUT
(CONTROL/SERVICE)
DC OUTPUT
(DC 12V)
Monitor Rear Connections Panel
• Connect the RS-232C (serial connector) input jack with the rear of moniter’s RS-232C
input jack.
• RS-232C connection cables are not supplied with the Monitor.
How to To Connect External Control Equipment
External Control Device Setup
