Zero SR/S User Manual

45-16 Brakes
Brakes
45
7. Raise rear tire and remove rear WSS and set
aside.
Note: Make sure the WSS is supported and is
not straining the WSS harness.
8. Lower the rear tire carefully to keep from
damaging painted surfaces.
9. Place rag over the left side of the swingarm
between the rear sprocket and the swing arm
to protect painted surfaces.
10. Roll rear tire forward.
11. Release rear brake hose from the metal
retaining clip.
12. Position the rear brake hose on top of clip.
13. Tip the top of the rear tire to the left.

Zero SR/S Specifications

General

Category	Motorcycle
Peak Power	110 hp (82 kW)
Continuous Power	54 hp (40 kW)
Torque	140 ft-lb (190 Nm)
Range (City)	161 miles (259 km)
Range (with Power Tank)	200 miles (322 km)
Top Speed (Max)	124 mph (200 km/h)
Top Speed (Sustained)	110 mph (177 km/h)
Front Tire	120/70 ZR17
Rear Tire	180/55 ZR17
Motor	Z-Force 75-10
Battery	ZF14.4 Lithium-ion
Range (Highway)	82 miles (132 km) at 70 mph
Seat Height	787 mm (30.9 in)
Wheelbase	1, 450 mm (57.1 in)
Front Suspension	Showa 41 mm
Rear Suspension	Showa 40mm piston, piggy-back reservoir shock
Front Brake	Dual J-Juan asymmetric piston calipers, 320 x 5 mm discs
Rear Brake	J-Juan single piston floating caliper with 240mm disc
ABS	Bosch Gen 9
Charging Time (Standard)	4.5 hours
