Section 11.0

MAN 06–0017H

ZIEHM QUANTUM User’s Manual Page 171 of 220

• Adjust the steering lever to position the steering wheels at 90 degrees to the C-Arm body.

Example Fig 11.4.

• Lower the vertical shaft while guiding the generator assembly into the generator cradle.

Continue until the vertical shaft is at 0cm. Example Fig 11.5
