9.4
PORT
2
Port
2
is
a
general-purpose
port.
Each
of
its
lines
can
be
independently programmed as
input
or
output
via
the
Port
2
Mode
register
(Figure
9-9).
A
bit
set
to
a 1
in
P2M
configures
the
correspond-
ing
bit
in
Port
2 as
an
input,
while a
bit
set
to
o determines
an
output
line.
R246
P2M
Port 2 Mode Register
(%
F6;
Write
Only)
P2o-P27 MODE
'------
0 OUTPUT
1 INPUT
figure
9-9.
Port
2 I/O Operation
9.4.1
Read/Write
Operations
Port
2
is
accessed
as
general-purpose
register
P2
(%02).
The
port
is
written
by
specifying
P2
as
an
instruction's
destination
register.
Writing
the
port
causes
data
to
be
stored
in
the
port's
output
register,
and
reflected
externally
on
any
bit
con-
figured
as
an
output.
The
port
is
read
by
specifying
P2
as
the
source
register
of
an
instruction.
When
an
output
bit
is
read,
data
on
the
external
pin
is
returned.
Under
normal
loading
conditions,
this
is
equivalent
to
reading
the
output
register.
However,
if
a
bit
of
Port
2
is
defined
as
an
open-drain
output,
the
data
returned
is
the
value forced
on
the
output
pin
by
the
external
system. This
may
not be
the
same
as
the
data
in
the
output
register.
Reading
input
bits
of
Port
2
also
returns
data
on
the
external
pins.
However,
inputs
under hand-
shake
control
return
data
latched
into
the
input
register
via
the
input
strobe.
I/O
Ports
9.4.2
Handshake
Operation
Port
2 can be
placed
under handshake
control
by
programming
the
Port
3
Mode
register
(Figure
9-10).
In
this
configuration,
Port
3
lines
P31
and
P36
are
used
as
the handshake
control
lines
DAV2
and
RDY2
for
input
handshake,
or
RDY2
and
DAV
2
for
output
handshake.
R247
P3M
Port 3 Mode Register
(%
F7;
Write
Only)
o
P3l
= INPUT (TIN) P3s = OUTPUT
(TOUT)
1
P3l
= DAV2JRDY2 P3s = RDY2JDAV2
Figure
9-10.
Port
J Handshake
Operation
Handshake
direction
is
determined
by
the
configu-
ration
(input
or
output)
assigned
to
bit
7
of
Port
2. Only
those
bits
with
the
same
configuration
as
P2
7
will
be under handshake
control.
Figure
9-11
illustrates
Port
2's
bit
lines
and
the
associated
handshake
lines
of
Port
3.
P20
PORT
2(1/0)
P27
}
HANDSHAKE
CONTROLS
DAV2
AND
RDY2
(P3
1
AND
P3
s
)
figure
9-11.
Port
2
2037-014,3047-010,2037-008
9-5
