ZiLOG Z8 Technical Manual

-A-
Address/Data bus (see Bus operations)
Addressing modes, 2:2ff, 3:1, 3:6
Direct Addressing (DA), 2:2, 3:1, 4:1, 4:3
Immediate Data addressing (1M), 2:2, 4:1, 4:4
Indirect Register addressing (~), 2:2, 3:1,
4: 1, 4:2
Indexed
addressing (X), 2:2, 3:1, 4:1, 4:2
Register addressing (R), 2:2, 3:1, 4:1
Relative addressing (RA), 2:2, 4:1, 4:3
Address spaces, 2:1, 3:1ff
Data memory, 2:1, 3:1, 3:5, 7:4
Program memory, 2:1, 3:1, 3:3
Address Strobe
(AS) signal, 3:3, 6:1, 6:3, 6:4,
7:1, 7:5,
8:1
ZB601/11, 6:1, 6:3, 6:4
ZB681/82, 7:1, 7:5
Applications, Z8 Family, 1:4
Assembly language syntax, 5:4
-8-
BASIC/Debug interpreter (Z8671), 1:1, 1:2, 1:4
8CD operations, 2:2
Bit rate generation, 2:2, 12:1ff
Bus operations, 6:3, 6:5, 7:5
Bus timing, 6:6, 7:5
-c-
Carry flag (C) (see Flags)
Clock, 8:2ff
Capacitors, 8:2
Crystal frequency, 8:2
Oscillator, 1:1, 1:3, 8:2
V
CC
' 8:3
V
HM
, 8:3
Condition codes, 5:3, 5:4, 5:5
Control lines, 3:3
Control registers, 3:3, B:1
Counter/timers, 1:1, 1:3, 1:4, 2:2, 11:1ff
Cascaded, 11:8
Continuous
mode, 11:1ff
Enable Count bit, 11:3
Load bit, 11:3
Reset
conditions, 11:9
Index
Counter/Timers (cont'd)
Single-Pass mode, 8:1, 11:1ff
TIN modes, 11:5ff
TOUT modes, 11:4
Counter/timer registers (T1, TO), 3:3, 11:1ff
Crystal1, 2 (XTAL1, 2) sign~ls, 7:2, 8:2
-0-
Data Available (DAV) signal, 9:8
Data memory, 2:1, 3:1, 3:5, 7:4
Data Memory (OM) signal, 1:4, 3:5, 6:1, 6:3, 6:10,
7:4, 7:5
Data Strobe
(DS) signal, 3:3, 6:1, 6:3, 6:4, 7:1,
7:5, 8: 1
Z8601/11, 6:1, 6:3
Z8681/82, 7:1, 7:5
Data
types, 1:1, 2:2
Decimal-Adjust flag (D) (see Flags)
Development device (l8612), 1:1, 1:2, 1:3, A:1
Development Module (DM), 1:1
Direct Address (DA) (see Addressing modes)
-E-
Enable Count bit, 11:3
EPROM, 2K and 4K, 1:2, 1:4
Error conditions, 3:2, 12:4, 12:6
Framing
errors, 12:4
Overwrites, 12:4, 12:6
in register use, 3:2
External interface operations, 6:1ff, 7:1ff
Z8601/11, 6:1 ff
Z8681, 7:1ff
l8682, 7:1ff
-F-
Flags, 5:2ff
Carry (C), 5:2
Decimal-Adjust
(DA), 5:3
Half-Carry (H), 5:3
Overflow (V), 5:3
Sign
(S), 5:2
Zero (l), 5:2
Flag register, 5:1
1-1
