-5-
Serial I/O register (510), 3:3, 12:1ff, 12:6
Sign flag (5) (see flags)
Singlo-pass counting mode, 8:1, 11:lff
Stack, 3:6, 6:3, 7:4
External, 6:3, 7:4
Internal, 3:6
Stack Pointer (SP), 3:3, 3:6
-T-
Test mode, 8:4ff
for interrupts, 8:5
and ROMless operation, 8:5
Timers (see Counter/timers)
Timer Mode register (TMR), 3:3, 11:3, 12:3
TIN modes, 11:5ff
External clock input, 11:6
Gated
internal clock, 11:6
Retriggerable
internal clock, 11:8
Triggered
internal clock, 11:8
TOUT modes, 11:4
Transmitter, 12:4
-U-
UART (Universal Asynchronous Receiver/
Transmitter), 1:1, 1:3, 1:4, 2:2
-x-
XTAL1, XTAL2 (Crystal 1, 2 signals), 6:2
-z-
Zero flag (Z) (see Flags)
Z8 Development Module (OM), 1:1, 1:2
Z8 Emulator (Z-SCAN 8), 1:1, 1:2
Z8601/11 Microcomputer, 1:1, 1:2, 1:3, 6:1ff
Initialization, 6:2
Pin functions and assignments, 6:1
Z8603/13 Protopack, 1:1, 1:2, 1:4, 2:2, A:l
Pin descriptions and functions, A:l
Z8612 development device, 1:1, 1:2, 1:3, A:l
Pin descriptions and functions, A:l
Z8671 BASIC/Debug interpreter, 1:1, 1:2, 1:4
Z8681 ROMless, 1:1, 1:2, 1:4, 3:3, 7:1ff
Initialization, 7:2
Pin functions and assignments, 7:1
Z8682 ROMless, 1:1, 1:2, 1:4, 7:1ff
Initialization, 7:3
Pin functions and assignments, 7:1
