GIGABIT/FAST ETHERNET SWITCH TYPE SWT 103/137
USER GUIDE - M0SWTA1903Iv09 - V09 March 2019
Access through the SRV port
Local mode access is obtained through a flat serial cable that connects the serial port of the
computer to the serial port of the equipment (SRV).
Communication between the computer and the equipment is established through a terminal
emulation programme, such as Windows® HyperTerminal, configuring a serial connection
with the following characteristics:
• Speed: 115.200 bps
• Data bits: 8
• Parity: No
• Stop bits: 1
• Flow control: No
In Windows XP
©
execute HyperTerminal from Start → All Programmes → Accessories →
Communications → HyperTerminal (see FIGURE 59).
FIGURE 59 Location of HyperTerminal in Windows XP
©
