Inserting SD cards
SD card slot on
lower left side
1.
Turn the power off and then open the SD card slot cover.
2.
Insert the SD card into the SD card slot.
To remove an SD card, push it further into the slot and then pull it out.
NOTE
• Always turn the power off before inserting or removing an SD card.
Inserting or removing a card while the power is on could result in data loss.
• When inserting an SD card, be sure to insert the correct end with the top side up as shown.
• If an SD card is not loaded, recording and playback are not possible.
• After purchasing a new SD card, always format it using the
H8 to maximize performance.
(
→
“Formatting SD cards” on page 112)
17
