Zoom H8 - Page 24

Input A Input B
Hi-Z switches A/B
Connecting mixers and similar devices
Connect XLR cables from keyboards and mixers directly to Inputs 1–4.
For mixers and other devices with a rated output level of +4 dB, set the corresponding PAD switches (
) to
–20dB.
Input 1
Input 2
Input 3
Input 4
PAD switches 3/4
PAD switches 1/2
HINT
When connecting an ordinary mic, set the PAD switch to 0dB.
24
