Chapter 11 Static Multicast Forward Setup
XGS4700-48F User’s Guide
144
connected to port 3. Figure 58 shows frames being forwarded to ports 2 and 3
within VLAN group 4.
Figure 56 No Static Multicast Forwarding
Figure 57 Static Multicast Forwarding to A Single Port
Figure 58 Static Multicast Forwarding to Multiple Ports
11.2 Configuring Static Multicast Forwarding
Use this screen to configure rules to forward specific multicast frames, such as
streaming or control frames, to specific port(s).
