Chapter 38 DVMRP
XGS4700-48F User’s Guide
348
4 The final multicast (“M”) after pruning and grafting is shown in the next figure.
Figure 176 How DVMRP Works
38.2.1 DVMRP Terminology
DVMRP probes are used to discover other DVMRP Neighbors on a network.
DVMRP reports are used to exchange DVMRP source routing information. These
packets are used to build the DVMRP multicast routing table that is used to build
source trees and also perform Reverse Path Forwarding (RPF) checks on incoming
multicast packets. RPF checks prevent duplicate packets being filtered when loops
exist in the network topology.
DVMRP prunes trim the multicast delivery tree(s). DVMRP grafts attach a branch
back onto the multicast delivery tree.
38.3 Configuring DVMRP
Configure DVMRP on the Switch when you wish it to act as a multicast router
(“mrouter”). Click IP Application > DVMRP in the navigation panel to display
the screen as shown.
Figure 177 IP Application > DVMRP
