XGS4700-48F User’s Guide
455
CHAPTER 55
Product Specifications
The following tables summarize the Switch’s hardware and firmware features.
Table 169 Hardware Specifications
SPECIFICATION DESCRIPTION
Dimensions Standard 19” rack mountable
438 mm (W) x 425 mm (D) x 44.45 mm (H)
Weight 5.4 Kg
Power Specification AC: 100 - 240 VAC 50/60 Hz 1.6 A max, 143 W internal universal
power supply
DC: -36 VDC ~ -72 VDC 3.7 A max, 130 W consumption. There is
no tolerance for the DC input voltage.
Interfaces 48 mini-GBIC slots, compatible with Small Form-Factor Pluggable
(SFP) Multi Source Agreement (MSA) transceivers.
Two slots for optional 10G uplink module sets.
One local management Ethernet 10/100Base-T port
One RS-232 console port
LEDs Main switch: PWR1, PWR2, SYS, ALM
The 100Base-T management port: MGMT
Green: 10 Mbps
Amber: 100 Mbps
Per mini-GBIC port: 1~48
steady: link state
blinking: transmitting/receiving
Per stacking port: 49~52
Operating
Environment
Temperature: 0º C ~ 45º C (32º F ~ 113º F)
Humidity: 10 ~ 90% (non-condensing)
Storage Environment Temperature: -10º C ~ 70º C (-13º F ~ 158º F)
Humidity: 10 ~ 90% (non-condensing)
Ground Wire Gauge 18 AWG or larger
Power Wire Gauge 18 AWG or larger
