ZyXEL Communications XGS4700-48F - Reload the Configuration File

Chapter 4 The Web Configurator
XGS4700-48F User’s Guide
63
4.6.1 Reload the Configuration File
Uploading the factory-default configuration file replaces the current configuration
file with the factory-default configuration file. This means that you will lose all
previous configurations and the speed of the console port will be reset to the
default of 9600bps with 8 data bit, no parity, one stop bit and flow control set to
none. The password will also be reset to “1234” and the IP address to
192.168.1.1.
To upload the configuration file, do the following:
1 Connect to the console port using a computer with terminal emulation software.
See Section 3.2 on page 46 for details.
2 Disconnect and reconnect the Switch’s power to begin a session. When you
reconnect the Switch’s power, you will see the initial screen.
3 When you see the message “Press any key to enter Debug Mode within 3
seconds ...” press any key to enter debug mode.
4 Type atlc after the “Enter Debug Mode” message.
5 Wait for the “Starting XMODEM upload” message before activating XMODEM
upload on your terminal.
6 After a configuration file upload, type atgo to restart the Switch.
Figure 27 Resetting the Switch: Via the Console Port
The Switch is now reinitialized with a default configuration file including the default
password of “1234”.
Bootbase Version: V1.00 | 01/13/2011 19:34:13
RAM: Size = 524288 Kbytes
ZyNOS Version: V4.00(BVG.0)b6 | 01/28/2011 14:44:24
Press any key to enter debug mode within 3 seconds.
.....................................
Enter Debug Mode
ras> atlc
Starting XMODEM upload (CRC mode)....
CCCCCCCCCCCCCCCC
Total 393216 bytes received.
Erasing..
................................................................
OK
ras> atgo
