XGS4700-48F User’s Guide
177
CHAPTER 16
Mirroring
This chapter discusses port mirroring setup screens.
16.1 Port Mirroring Setup
Port mirroring allows you to copy a traffic flow to a monitor port (the port you copy
the traffic to) in order that you can examine the traffic from the monitor port
without interference.
Click Advanced Application > Mirroring in the navigation panel to display the
Mirroring screen. Use this screen to select a monitor port and specify the traffic
flow to be copied to the monitor port.
Figure 77 Advanced Application > Mirroring
