Chapter 17 Link Aggregation
XGS4700-48F User’s Guide
182
Criteria This shows the outgoing traffic distribution algorithm used in this trunk
group. Packets from the same source and/or to the same destination are
sent over the same link within the trunk.
src-mac means the Switch distributes traffic based on the packet’s source
MAC address.
dst-mac means the Switch distributes traffic based on the packet’s
destination MAC address.
src-dst-mac means the Switch distributes traffic based on a combination
of the packet’s source and destination MAC addresses.
src-ip means the Switch distributes traffic based on the packet’s source IP
address.
dst-ip means the Switch distributes traffic based on the packet’s
destination IP address.
src-dst-ip means the Switch distributes traffic based on a combination of
the packet’s source and destination IP addresses.
Status This field displays how these ports were added to the trunk group. It
displays:
• Static - if the ports are configured as static members of a trunk group.
• LACP - if the ports are configured to join a trunk group via LACP.
Table 41 Advanced Application > Link Aggregation Status (continued)
LABEL DESCRIPTION
