Chapter 2. Start H7016
2-7
2
6. Status display (LED)
• POWER LED
- This LED turns on when the power is on.
• REC LED
- This LED turns on when system is writing data to the HDDs
• NET LED
- This LED turns on when the system is connected to the network
• IR Sensor
Press once : 1 frame Rev.Playback.
Press twice: to Jump 30min in the
rev. playback direction.
.
Press once : 1 frame Playback
Press Twice: to jump 30min in the
playback direction.
