Post-installation Checks 35
Post-installation
Checks
This section describes the LEDs and basic checks that you can use to verify
your installation, and to ensure that the Switch and module are operating
correctly.
LED Summary This section describes the Switch LEDs that provide status and
troubleshooting information.
For information on solving problems after installation, see Chapter 9.
Table 10 IP Default Values for Each Interface
Parameter Default Value
OSPF ■ OSPF disabled on each new IP interface
■ Hello timer = 10 seconds*
■ Retransmit = 5 seconds*
■ Dead interval = 40 seconds*
■ Area ID = 0.0.0.0 for each interface
■ No password
■ Interface cost = 1
■ Priority = 1
RIP ■ RIP is enabled and will learn, but not advertise routes
■ Interface cost = 1
■ Poison reverse = enabled
■ No additional advertisement addresses are defined
Table 11 Switch Module Status LEDs
LED Name Color/State Indicates
Packet Yellow Packets are being routed.
Off No packets are being routed.
Status Yellow The Layer 3 Module is functioning.
Yellow
flashing
An unrecognized or faulty module is installed in
the Switch.
Off There is no module installed in the Switch.
