90 CHAPTER 8: SETTING IP PARAMETERS
Displaying OSPF
Interface Statistics
To display statistics associated with specific OSPF interfaces:
1 Enter the following at the top-level menu:
ip ospf interface statistics
The following prompt is displayed:
Select IP interfaces (1-2|all):
2 Select an IP interface.
State Interface state:
■ Disabled= OSPF is not enabled on the interface.
■ Down= The interface is down, but OSPF is enabled on it.
■ Loopback= The interface is a loopback interface.
■ Waiting= The router is trying to determine the identity of
the DR and BDR on the network.
■ PTP= The interface is operational and connects to either a
point-to-point network or a virtual link. The router attempts
to form adjacency with the neighboring router.
■ DRother= The interface is on a multi-access network where
this router is not the DR or BDR.
■ DR= The router is the DR on the attached network.
DR Router ID of the designated router (DR).
BDR Router ID of the backup designated router (BDR).
Notes When RouterID appears, the interface address is being used
as the OSPF router ID.
Table 20 Field Attributes for the OSPF Interface Displays (continued)
Field Description
