42 CHAPTER 5: USING THE WEB INTERFACE
Figure 11 Web Management Interface
■ Tabs panel — Located at the top of your browser window and
contains the WebConsole tab. The WebConsole tab
displays a menu
tree that lists the parameters that you can configure for the selected
device.
■ Menu tree — Lists system menu options, much like the user
interface. Click a menu item to view the associated form in the
workspace.
■ Workspace — Displays forms for the selected menu option.
When a Telnet icon appears besides a device name in the menu tree, you
can click the icon to launch a Telnet session to configure system
parameters which are not supported through the WebConsole.
Tabs panel
Menu tree
Workspace
