Autotest Configurations
The following tables list the tests performed for the
Inactive Pair, Active Pair and Wideband Tests.
Test Basic Full Pass/Fail
Vdc Yes Yes No
Ohms Yes Yes Yes
Opens Yes Yes No
Long. Balance Yes Yes Yes
Load Coil No Yes No
Inactive Pair Tests without FED
Vdc Yes Yes No
Ohms Yes Yes Yes
Opens Yes Yes No
Long. Balance Yes Yes yes
Voiceband Scope No Yes No
Single Tone Loss Yes No Yes
Loop Resistance No Yes Yes
Load Coil No Yes No
Inactive Pair Tests with FED
Vdc No
Loop Current Yes
Ground Resistance Yes
Loss Yes
Noise Yes
Power Influence Yes
Long Balance dB Yes
Noise Balance Yes
Active Pair Tests (without FED)
