Autotest Results Screen Symbol Definitions
- DC Volts measurement results
- Ohms measurement results
- Opens measurement results
- Longitudinal balance measurement result
- Load coil detect/distance to first load coil
- Loop current measurement result
- Ground Resistance measurement
- Single frequency loss measurement result
- Metallic Voiceband or Wideband noise
measurement result
- Power influence measurement result
- Balance measurement result (longitudinal
or noise)
- Noise balance measurement result (Power
influence - Noise)
- Loop ohms measurement result
- Capacitive balance measurement result
- General pass/fail loss measurement
- Resistive balance measurement result
- Voice-band frequency slope measurement
result
- HDSL2/4 Loop Attenuation measurement
