Volume measurement setting
Process Info Device parameter to be configured
TAG PB_TAG_DESC
Calibration LRV 0% PRTB_SCALE_IN 0%
Calibration URV 100% PRTB_SCALE_IN 100%
Calibration Unit PRTB_SECONDARY_VALUE_1_UNIT
Linearization Type PRTB_LIN_TYPE
linearisation table
cylindrical lying container
spherical container
Output scale 0%
AI1_OUT_SCALE 0%
AI1_PV_SCALE 0%
PRTB_SCALE_OUT 0%
Output scale 100%
AI1_OUT_SCALE 100%
AI1_PV_SCALE 100%
PRTB_SCALE_OUT 100%
Output Scale Unit
AI1_OUT_SCALE Unit Code
PRTB_PRIMARY_VALUE_UNIT
Further common setting
Process Info Device parameter to be configured
Node Address
Damping AI1_PV_FTIME
Critical Limit Low AI1_LO_LO_LIM
Advisory Limit Low AI1_LO_LIM
Advisory Limit High AI1_HI_LIM
Critical Limit High AI1_HI_HI_LIM
Alarm Hysteresis AI1_ALARM_HYS
Fail Safe Type AI1_FSAFE_TYPE
No field calibration is normally requested, the transmitter has
been trimmed to the calibration points (URV and LRV) to
provide the best performances in the real operating range.
In case the calibrated range has to be changed, please refer to
the section 12 in this manual
