SLOT 4 --- n = 16
STANDARD PARAMETERS
Idx Parameter Data Type Size Storage Class Range Note
n+0 BLOCK_OBJECT R R DS_32 20 Cst
n+1 ST_REV R S U16 2 N
n+2 TAG_DESC RW S O_STR 32 S
n+3 STRATEGY RW S U16 2 S
n+4 ALERT_KEY RW S U8 1 S
n+5 TARGET_MODE RW S U8 1 S AUTO
n+6 MODE_BLK R R DS_37 3 D
n+7 ALARM_SUM R R DS_42 8 D
n+8 SENSOR_VAL R S FLT 4 D Process Value before the Calibration (0)
Expr. in SENSOR_UNIT (idx n+14)
n+9 SENSOR_HI_LIM R S FLT 4 N Upper sensor limit
n+10 SENSOR_LO_LIM R S FLT 4 N Lower Sensor limit
n+11 CAL_POINT_HI RW S FLT 4 S Upper Calibration Point
n+12 CAL_POINT_LO R/W S FLT 4 S Lower Calibration Point
n+13 CAL_MIN_SPAN R S FLT 4 N Calibration Minimum Span
n+14 SENSOR_UNIT RW S U16 2 S Pressure Units ONLY [Kpa]
n+15 TRIMMED_VALUE R R 101 5 D Process value after the Calibration (1) Expr. in SENSOR_UNIT (idx n+14)
n+16 SENSOR_TYPE R S U16 2 N Sensor Type
n+17 SENSOR_SERIAL_NUMBER R S U32 4 N Sensor Serial Number
n+18 PRIMARY_VALUE R R 101 5 D Proc. Val out of PRTB and input to the AI_1 (4) Expr.in PRIMARY_VALUE_UNIT (idx n+19)
n+19 PRIMARY_VALUE_UNIT RW S U16 2 S Primary Value Unit [Kpa] All Units available
n+20 PRIMARY_VALUE_TYPE RW S U16 2 S PV type = Press, Level, Flow, Volume
n+21 SENSOR_DIAPHRAGM_MATERIAL RW S U16 2 S Sensor Diaphragm material
n+22 SENSOR_FILL_FLUID RW S U16 2 S Sensor Fill Fluid
n+23 SENSOR_MAX_STATIC_PRESSURE R S FLT 4 N Max Sensor Working Pressure Expr. in SENSOR_UNIT (idx n+14)
n+24 SENSOR_O_RING_MATERIAL_HSP RW S U16 2 S Sensor O-Ring Material
High Siden+25 PROCESS_CONNECTION_TYPE_HSP RW S U16 2 S Process connection type
n+26 PROCESS_CONNECTION _MATERIAL_HSP RW S U16 2 S Process connection material
n+27 TEMPERATURE R R 101 5 D Sensor temperature
n+28 TEMPERATURE_UNIT RW S U16 6 S Temperature Units [°C}
n+29 SECONDARY_VALUE_1 R R 101 16 D Process value after Bias/Offset (2)
n+30 SECONDARY_VALUE_1_UNIT RW S U16 2 S Pressure Units ONLY [Kpa]
n+31 SECONDARY_VALUE_2 R R 101 5 D Process Value after the Input Scaling (3) Expr.in SECONDARY_VALUE_2_UNIT (idx n+32)
n+32 SECONDARY_VALUE_2_UNIT RW S U16 2 S No unit No unit = 1997
