Appendix A – Device mapping
Idx Parameter Data Type Size Storage Class Range Note
n+33 LIN_TYPE RW S U8 1
0: Linear (default)
1: linearisation table 10: Square root 20: cylindrical lying container 21: spherical container 240: SQRT 3° pow 241: SQRT 5° pow 242: Bidirectional Flow
n+34 SCALE_IN R/W A FLT 8 S Process Value Input/Calibration Scale Expr.in SECONDARY_VALUE_1_UNIT (idx n+30) n+35 SCALE_OUT R/W A FLT 8 S PRTB Output Scale Expr.in PRIMARY_VALUE_UNIT (idx n+19) n+36 LOW_FLOW_CUT_OFF R/W S FLT 4 S 0% to 20% [6%]
Only for LIN_TYPE = Sqr.Root or Bidirectional Flow
n+37 FLOW_LINEAR_SQRT_POINT R/W S F LT 4 S 0% or 5% to 20% [5%]
n+38 TAB_ACT_NUM R S U8 1 Number of valid points in the TABLE
n+39 TAB_ENTRY R/W S U8 1 Pointer to the TAB_X_Y_VAL Array n+40 TAB_MAX_NUM R S U8 1 Max number of supported points = 22 n+41 TAB_MIN_NUM R S U8 1 Min number of supported points = 2 n+42 TAB_OP_CODE R/W S U8 1
0: Not initialized
1: New op. char., first value TAB_ENTRY=1 (Idx 39) 2: Reserved 3: Last value, End of transmission,
n+43 TAB_STATUS R S U8 1 Feed-back of the new TABLE writing/setting n+44 TAB_X_Y_VAL R/W A FLT 8 TABLE values as couple of X, Y values n+45 MAX_SENSOR_VALUE R/W S FLT 4 N Max Historical Sensor value
Expressed in SENSOR_UNIT (idx n+14)
n+46 MIN_SENSOR_VALUE R/W S FLT 4 N Min Historical Sensor value
n+47 MAX_TEMPERATURE R/W S FLT 4 N Max Historical temp. value
Expr. in TEMPERATURE_UNIT (idx n+28)
n+48 MIN_TEMPERATU/RE R/W S FLT 4 N Min Historical temp. value
49-58 NULL_ // reserved by PNO
MANUFACTURER SPECIFIC PARAMETERS
Idx Parameter Data Type Size Storage Class Range / Selection Note
n+59 DRAIN_VENT_MATERIAL_HSP R/W S U16 2 S Drain vent Material High Side n+60 SENSOR_O_RING_MATERIAL_LSP R/W S U16 2 S Sensor O-Ring Material
Low Side
n+61 PROCESS_CONNECTION_TYPE_LSP R/W S U16 2 S Process connection type n+62 PROCESS_CONNECTION _MATERIAL_LSP R/W S U16 2 S Process connection material n+63 DRAIN_VENT_MATERIAL_LSP R/W S U16 2 S Drain vent Material n+64 GAUGE_ABS_PROC_CONNECT_MTL R S U16 2 N Process connection material for Gauge or Absolute sensor types n+65 REMOTE_SEALS_TYPE_HSP R S U16 2 N Remote Seal type
High Siden+66 REMOTE_SEALS_FILL_FLUID_HSP R S U16 2 N Remote Seal Fill Fluid
n+67 REMOTE_SEALS_ISOLATOR_HSP R S U16 2 N Remote Seal Isolator n+68 REMOTE_SEALS_TYPE_LSP R S U16 2 N Remote Seal type
Low Side
n+69 REMOTE_SEALS_FILL_FLUID_LSP R S U16 2 N Remote Seal Fill Fluid
