2600T Series Pressure transmitters | OI/266/PB-EN Rev. E 45
12 Operations
12.5 Savings
In order to keep a valid device setting to be used as reference
when a valid condition has to be recovered in case of wrong
operations, it is possible save all the above calibrations as
Factory or User calibrations and the complete device
configuration.
The possible savings are the following and are executed writing
the proper code in the PB_SAVINGS, for details refer to the
APPENDIX A - Device Mapping Tables.
Save
Configuration
as Default
When this operation is executed, the complete device
configuration is saved as default configuration at which the
device returns when the Reset to Default configuration is
executed. After the device has been properly configured,
the user can decide to save it as a default configuration in
order to recover it if necessary
Save
P-dP Sensor
as Factory
Calibration
The P-dP Sensor calibration/trimming is saved as
Factory Calibration. This operation is typically executed
in the Factory after the Sensor has been calibrated to
the customer‘s specified measuring range or, in case the
customer didn’t requested any measuring range, at the
maximum sensor range
Save Static
P Sensor as
Factory
Calibration
The Static P Sensor calibration/trimming is saved as
Factory Calibration.
Save Sensor
Temp as
Factory
Calibration
The Sensor Temp. calibration/trimming is saved as
Factory Calibration
Save as User
P-dP Sensor
Trimming
The P-dP Sensor calibration/trimming is saved as User
Calibration. This operation is typically executed by the
user after the Sensor has been calibrated at the desired
measuring range.
Save as
User Static
P Sensor
Trimming
The Static P Sensor calibration/trimming is saved as User
Calibration
Save as User
Sensor Temp
Trimming
The Sensor Temp. calibration/trimming is saved as User
Calibration
12.6 Reset
The transmitter offers some reset operations executed by
writing the proper code in the PB_FACTORY_RESET, for
details refer to the APPENDIX A - Device Mapping Tables
Reset to Default
Values
When this operation is executed, the complete
device configuration returns to the configuration
previously saved as default configuration.
Warm Start-up
This operation executes a S software restart
Reset Bus address
to default (126)
Reset only the Device Address to the default
address (126)
Reset P-dP
Sensor to Factory
Calibration
Return the P-dP Sensor calibration/trimming at the
calibration previously saved as Factory Calibration
This operation can be executed also with the
optional keypad from the menu “Calibration/
Reset/Factory Sens Trimming”
Reset Static P
Sensor to Factory
Calibration
Return the Static Pressure Sensor calibration/
trimming at the calibration previously saved as
Factory Calibration
Reset Sensor
Temp to Factory
Calibration
Return the Sensor temperature calibration/
trimming at the calibration previously saved as
Factory Calibration
Reset to User P-dP
Sensor Trimming
Return the P-dP Sensor calibration/trimming at the
calibration previously saved as User Calibration.
This operation can be executed also with the
optional keypad from the menu “Calibration/
Reset/User Sens Trimming”
Reset to User
Static P Sensor
Trimming
Return the Static Pressure Sensor calibration/
trimming at the calibration previously saved as
User Calibration
Reset to User
Sensor Temp
Trimming
Return the Sensor temperature calibration/
trimming at the calibration previously saved as
User Calibration
