SLOT 6 --- n = 16
Idx Parameter Data Type Size Storage Class Range Note
n+0 BLOCK_OBJECT R R DS_32 20 Cst
n+1 ST_REV R S U16 2 N
n+2 TAG_DESC RW S O_STR 32 S
n+3 STRATEGY RW S U16 2 S
n+4 ALERT_KEY RW S U8 1 S
n+5 TARGET_MODE RW S U8 1 S AUTO
n+6 MODE_BLK R R DS_37 3 D
n+7 ALARM_SUM R R DS_42 8 D
n+8 CONTRAST RW S U8 1 Display Contrast 0 ….100 [50]
n+9 LANGUAGE RW S U8 1 S
0: English (default)
1: German
2: French
3: Spanish
4: Italian
n+10 HMI_MODE RW S U8 1 S
5: One Line
6: One Line with Bargraph (default)
9: Two Lines
10: Two Lines with Bargraph
n+11 HMI_SW_REV R S U8 1 N
0 Not Installed
xxx Display SW Revision
n+12 HMI_LIN_TYPE RW S U8 1 S
0: Linear (default)
Active only if one of the 4 HMI_Variable_x is set to HMI_Scaled_Output .
In this case the PRTB_SECONDARY_VALUE_2 is calculated with the selected
HMI_LIN_TYPE and the result ready to be scaled with the HMI_VARIABLE_
RANGE.
1: linearisation table
10: Square root
20: cylindrical lying container
21: spherical container
240: SQRT 3° pow
241: SQRT 5° pow
242: Bidirectional Flow
n+13 HMI_VARIABLE_RANGE RW R 11 S
EU100% , EU0%, Unitcode,
n°decimals
Scaling applied at the linearized value of the PRTB_SECONDARY_VALUE_2.
This value is for displaying purpose only and has not effect ont the real AIx_OUT
available through the Profibus Communication.
n+14 HMI_VARIABLE_CUSTOM_UNIT RW S V_STR 8 S Textual custom unit
n+15 HMI_LINE_1 RW S U8 1 S
1: HMI_Variable 1 (default)
2: HMI_Variable 2
3: HMI_Variable 3
4: HMI_Variable 4
n+16 HMI_LINE_2 RW S U8 1 S Same as HMI_LINE_1
n+17 HMI_BARGRAPH RW S U8 1 S Same as HMI_LINE_1
