Idx Parameter Data Type Size Storage Class Range Note
n+18 HMI_SEQUENCE RW S U8 1 S
0 Sequence/Autoscrolling OFF
1 Sequence/Autoscrolling ON
n+19 HMI_VARIABLE_1 RW S U8 1 S
In order to recognize the displayed variable among all those in this list, it appears a three character string in the left side of the value
when two lines mode is selected and below the value when One Line Mode is selected. The strings for any variables are:
0: Pressure (default) ‘PV ‘
10: AI_1 Output ‘AI1’
11: AI_1 O/P Percent ‘%1 ‘
12: AI_2 Output ‘AI2’
13: AI_2 O/P Percent ‘%2 ‘
14: AI_3 Output ‘AI3’
15: AI_3 O/P Percent ‘%3 ‘
7: Sensor Temp ‘ST ‘
8: Static Pressure ‘SP ‘
9: HMI Scaled Output ‘HMI’
16: Measured Value (Trimmed Value) ‘TPV ‘
n+20 HMI_VARIABLE_2 RW S U8 1 S Same as HMI_VARIABLE_1
n+21 HMI_VARIABLE_3 RW S U8 1 S Same as HMI_VARIABLE_1
n+22 HMI_VARIABLE_4 RW S U8 1 S Same as HMI_VARIABLE_1
VIEWS
n+134 VIEW_1 R 18 D
