Appendix B – Device diagnostic table
Sym Error HMI code Description Condensed Status Byte Classic Status Byte
Electronics errors AI1_OUT Process Val
AI2_OUT
Static Press
AI3_OUT
Sensor temp
AI1_OUT
Process Val
AI2_OUT
Static Press
AI3_OUT
Sensor temp
Memory Failure F116.023
The device data loaded at the start up are corrupted precluding the
correct functionality of the device
BAD Maintenance Alarm More
Diagnostic Available
GOOD- OK BAD Device Failure GOOD- OK
Electronic
Interface error
M030.020
Exchange of non-critical data between sensor and electronics is
precluded due to problem in the transmitter circuit of the electronics
or in receiver circuit of the sensor
GOOD Maintenance Required GOOD Maintenance Required
Non-Volatile
memory burn
error
M026.024
Writings to the electronic Non-Volatile Memory were not successful.
The device continue to work without problems but after the next
power cycle the last configuration will be lost
GOOD Maintenance Demanded GOOD Maintenance Required
Pressure Sensor errors AI1_OUT Process Val
AI2_OUT
Static Press
AI3_OUT
Sensor temp
AI1_OUT
Process Val
AI2_OUT
Static Press
AI3_OUT
Sensor temp
Sensor Invalid F120.016
The transducer is not in condition to generate a valid signal due to
one of the following conditions:
- The primary signal of the sensor is no longer available
- The sensor and the connected electronics are incompatible
BAD Maintenance Alarm More Diagnostic Available BAD Sensor failure
Sensor Memory
Fail
F118.017
The data in the sensor memory are corrupted precluding the correct
functionality of the device
BAD Maintenance Alarm More Diagnostic Available BAD Sensor failure
P-dP Sensor Fail F114.000
The sensor signal value is incorrect due to a mechanical failure i.e.
Loss of fill fluid from the cell; ruptured diaphragm, broken sensor….
BAD Maintenance Alarm
More Diagnostic
Available
GOOD- OK
BAD Sensor
failure
GOOD- OK
Static Pressure
Sensor Fail
F112.001
The sensor signal value is incorrect due to a mechanical failure i.e.
The circuitry for the sampling of the static pressure has failed……
Valid for Differential pressure models
BAD Maintenance Alarm More
Diagnostic Available
GOOD- OK
UNCERTAIN
Sen Conv Not
Accurate
BAD Sensor
failure
GOOD- OK
Sensor
Temperature Fail
F110.002
The circuitry for the sampling of the temperature has failed. The
accuracy is decreased more than the acceptable error
BAD Maintenance Alarm More Diagnostic Available
UNCERTAIN Sensor
Conversion Not Accurate
BAD Sensor
failure
Non-Volatile
memory burn
error
M028.018
Writings to the Sensor non-Volatile Memory were not successful. The
device continue to work without problems but any replacement
operation is compromised because the back-up configuration is not
updated
GOOD Maintenance Demanded GOOD Maintenance Required
