2600T Series Pressure transmitters | OI/266/PB-EN Rev. E 57
Appendix A – Device mapping
Device Management
SLOT 1
Idx Parameter Data Type Size Storage Class
0 DIRECTORY_OBJECT_HEADER R R Array U16 12 C 1
COMPOSITE_LIST_DIRECTORY_ENTRIES /
COMPOSITE_DIRECTORY_ENTRIES
R R Array U16
40
(12 + 28)
C
DIRECTORY_OBJECT_HEADER
Dir_ID Dir_Rev_Num Num_Dir_Obj Num_Dir_Entry First_Comp_ List_Dir_Entry Num_Comp_ List_Dir_Entry
0 1 1 10 1 3
COMPOSITE_LIST_DIRECTORY_ENTRIES
Begin_PB Num_PB Begin_TB Num_TB Begin_FB Num_FB
Slot Index Slot Index Slot Index
1 4 1 1 5 3 1 8 3
COMPOSITE_DIRECTORY_ENTRIES
PB_ID = 1 TB_ID = 1 TB_ID = 2
Start_PB Num_PB parameters Start_TB_1 Num_TB_1 parameters Start_TB_2 Num_TB_2 parameters
Slot Index Slot Index Slot Index
0 16 82 4 16 128 5 16 25
TB_ID = 3 FB_ID = 1 FB_ID = 2
Start_TB_3 Num_TB_3 parameters Start_FB_1 Num_FB_1 parameters Start_FB_2 Num_FB_2 parameters
Slot Index Slot Index Slot Index
6 16 23 1 16 45 2 16 45
FB_ID = 3
Start_FB_3 Start_FB_3
Slot Slot Slot
3 3 3
