SLOT 0 ---- n = 16
STANDARD PARAMETERS
Idx Parameter Data Type Size Storage Class Range Note
n+0 BLOCK_OBJECT R R DS_32 20 Cst
n+1 ST_REV R S U16 2 N
n+2 TAG_DESC RW S O_STR 32 S Default = “PI000”
n+3 STRATEGY RW S U16 2 S
n+4 ALERT_KEY RW S U8 1 S
n+5 TARGET_MODE RW S U8 1 S AUTO AUTO Only
n+6 MODE_BLK R R DS_37 3 D
n+7 ALARM_SUM R R DS_42 8 D
n+8 SOFTWARE_REVISION R S V_STR 16 Cst 01.00.00
n+9 HARDWARE_REVISION R S V_STR 16 Cst 01.00.00
n+10 DEVICE_MAN_ID R S U16 1 Cst 0x1A ABB
n+11 DEVICE_ID R S V_STR 16 Cst 0x07 2600T 266 PdP
n+12 DEVICE_SER_NUM R S V_STR 16 Cst
n+13 DIAGNOSIS R S O_STR 4 D
n+14 DIAGNOSIS_EXT R S O_STR 6 D
n+15 DIAGNOSIS_MASK R S O_STR 4 Cst 0x00,0x98,0x0F,0x80
n+16
R S O_STR 6 Cst 0x77,0x0C,0x97,0xC1,0xC1,0x04
n+17
R S V_STR 32 Cst
n+18 WRITE_LOCKING RW S U16 1 N
0 Write Locked
Software Write Locking
2457 Write Unlocked
n+19 FACTORY_RESET RW S U16 1 S
1 Reset to Default Values
Reset the device configuration to the configuration previously
saved with (idx 45) SAVINGS = 1
2506 Warm Start-up
Standard profile Reset types
2712 Reset Bus address to default (126)
32768 Reset P-dP Sensor to Factory Calibration
Reset Sensor calibrations at the calibration previously saved
as Factory with SAVINGS (index 45)
32769 Reset Static P Sensor to Factory Calibration
32770 Reset Sensor Temp to Factory Calibration
32771 Reset to User P-dP Sensor Trimming
Reset Sensor Calibration at the calibration previously saved
by the User with SAVINGS (index 45)
32772 Reset to User Static P Sensor Trimming
32773 Reset to User Sensor Temp Trimming
n+20 DESCRIPTOR RW S O_STR 32 S Descriptor
n+21 DEVICE_MESSAGE RW S O_STR 32 S Message
n+22 DEVICE_INSTAL_DATE RW S O_STR 16 S Installation date
n+23 LOCAL_OP_ENA RW S U8 1 N
0: disabled Local operation not allowed
1: enabled (default) Local operation allowed
