64 OI/266/PB-EN Rev. E | 2600T Series Pressure transmitters
Appendix A – Device mapping
Idx Parameter Data Type Size Storage Class Range / Selection Note
n+70 REMOTE_SEALS_ISOLATOR_LSP R S U16 2 N Remote Seal Isolator Low Side n+71 REMOTE_SEALS_NUMBER R S U8 1 N
1 One
2 Two 3 One on low side 4 One on high side 251 None
n+72 DESIRED_PRIMARY_VALUE R/W S FLT 4 N
Force the Measured Pressure to a selected Value setting an offset between Measured and Process values: PV = MV +/- BIAS: SECONDARY_VALUE_1 = TRIMMED_VALUE +/- BIAS_VALUE
Expr. in SECONDARY_VALUE_1_UNIT (idx n+30)
n+73 RESET_BIAS W S U8 1 N
Reset BIAS_VALUE to 0.0 so that SECONDARY_VALUE_1 = TRIMMED_VALUE
n+74 BIAS_VALUE R S F LT 4 N
Read the offset between the Measured and Process values: BIAS_ VALUE = TRIMMED_VALUE – SECONDARY_VALUE_1
Expr. in SECONDARY_VALUE_1_UNIT (idx n+30)
n+75 STATIC_P_SENSOR_HI_LIM R S FLT 4 N Static Pressure Sensor High Limit
Expr. in STATIC_P_SENSOR_UNIT (idx n+80)
n+76 STATIC_P_SENSOR_LO_LIM R S FLT 4 N Static Pressure Sensor Low Limit n+77 STATIC_P_CAL_POINT_HI R/W S FLT 4 S Static Pressure Calibration point High n+78 STATIC_P_CAL_POINT_LO R/W S FLT 4 S Static Pressure Calibration point Low n+79 STATIC_P_CAL_MIN_SPAN R S F LT 4 N Static Pressure Calibration minimum Span n+80 STATIC_ P_SENSOR_UNIT R/W S U16 2 S Pressure unit ONLY [Mpa] n+81 STATIC_P_TRIM_VALUE R R 101 5 D Static Pressure value after the Calibration (1) Expr. in STATIC_P_SENSOR_UNIT (idx n+80) n+82 STATIC _P_SEC_VALUE_1 R R 101 16 D Static Pressure value after Bias/Offset c(2) Expr.in STATIC_P_SEC_VALUE_1_UNIT idx n+83 n+83 STATIC_P_SEC_VALUE_1_UNIT R/W S U16 2 S Pressure Units ONLY [Mpa] n+84 STATIC_P_LIN_TYPE R/W S U8 1 S 0-Linear Fixed n+85 STATIC_P_SCALE_IN R/W A FLT 8 S Static Pressure input scale Expr.in STATIC_P_SEC_VALUE_1_UNIT idx n+83 n+86 STATIC_P_SCALE_OUT R/W A FLT 8 S Static Pressure output scale Expr. in STATIC_PRESS_UNIT (idx n+88) n+87 STATIC_PRESSURE_VALUE R R 101 5 D Static Pressure Value n+88 STATIC_ PRESSURE_UNIT R/W S U16 2 S Static Pressure unit [Mpa] All Units available n+89 DESIRED_STATIC_P_VALUE R/W S FLT 4 N
Force the Measured Pressure to a selected Value setting an offset between Measured and Process values: SP = MV +/- BIAS: STATIC_P_ SEC_VALUE_1 = STATIC_P_TRIM_VALUE +/- STATIC_P_BIAS_VALUE
Expr.in STATIC_P_SEC_VALUE_1_UNIT idx n+83
n+90 RESET_STATIC_P_BIAS ?W S U8 1 N
Reset BIAS_VALUE to 0.0 so that STATIC_P_SEC_VALUE_1 = STATIC_P_TRIM_VALUE
n+91 STATIC_P_BIAS_VALUE R S F LT 4 N
Read the offset between Measured and Process values: STATIC_P_ BIAS_VALUE = STATIC_P TRIM_VALUE – STATIC_P SEC_VALUE_1
Expr.in STATIC_P_SEC_VALUE_1_UNIT idx n+83
n+92 MAX_STATIC_PRESSURE_VALUE R/W S F LT 4 S Max Historical Static Press value
Expr.in STATIC_P_SENSOR_UNIT (idx n+80)
n+93 MIN_STATIC_PRESSURE_VALUE R/W S F LT 4 S Min Historical Static Press value n+94 SENSOR_TEMP_TRIM_VALUE R/W S FLT 4 S Sensor temperature calibration value
Expr. in TEMPERATURE_UNIT (idx n+28)n+95 HIGH_TEMPERATURE_LIMIT R S F LT 4 N Max operating sensor temperature Limit
n+96 LOW_TEMPERATURE_LIMIT R S FLT 4 N Min operating sensor temperature Limit n+97 SET_UPPER_RANGE_POINT_PV R/W S U8 1 N SPAN Button emulation for Process Value Write the instant measured val as SCALE_IN 100% n+98 SET_LOWER_RANGE_POINT_PV R/W S U8 1 N ZERO Button emulation for Process Value. Write the instant measured value as SCALE_IN 0%
