2600T Series Pressure transmitters | OI/266/PB-EN Rev. E 65
Appendix A – Device mapping
Idx Parameter Data Type Size Storage Class Range Note
n+99 SET_UPPER_RANGE_POINT_SP R/W S U8 1 N SPAN Button emulation for Static Pressure Writes the instant value in the STATIC_P_SCALE_IN 100% n+100 SET_LOWER_RANGE_POINT_SP R/W S U8 1 N ZERO Button emulation for Static Pressure Writes the instant value in the STATIC_P_SCALE_IN 0% n+101 PARALLEL_SHIFT_PV R/W S FLT 4 N
Shift the SCALE_IN range values in order to produce the desired percentage in output.
The SCALE_IN span remains unmodified
n+102 PARALLEL_SHIFT_STATIC R/W S FLT 4 N
Shift the STATIC_P_SCALE_IN range values in order to produce the desired percentage in out
The STATIC_P_SCALE_IN span remains unmodified
n+103 PRESSURE_SIMULATION_ENABLE R/W S U8 1 S
0: Disabled/OFF 1: Enabled/ON
n+104 PRESSURE_SIMULATION_VALUE R/W S FLT 4 S Pressure Simulation Value Expressed in SENSOR_UNIT (idx n+14) n+105 STATIC_PR_SIMULATION_ENABLE R/W S U8 1 S
0: Disabled/OFF 1: Enabled/ON
n+106 STATIC_PR_SIMULATION_VALUE R/W S FLT 4 S Static Pressure Simulation Value Expr.in STATIC_P_SENSOR_UNIT (idx n+80) n+107 SENSOR_TEMP_SIMULATION_ENABLE R/W S U8 1 S
0: Disabled/OFF 1: Enabled/ON
n+108 SENSOR_TEMP_SIMULATION_VALUE R/W S FLT 4 S Sensor temperature Simulation value Expr. in TEMPERATURE_UNIT (idx n+28) n+109 INTEGRATION_TIME R/W S U8 1 S From 0.01 to 1.28 seconds [0.3 s] For piezo sensor types only n+120 RESET_MIN_MAX_VALUES W S U8 1 N
1 Reset Sensor Values
Historical Resets for the User2 Reset Static P Values
3 Reset Temp Values
n+121 SERVICE_MAX_SENSOR_VALUE R/W S F LT 4 N For Service use. Max Historical Sensor value
Expressed in SENSOR_UNIT (idx n+14)
n+122 SERVICE_MIN_SENSOR_VALUE R/W S FLT 4 N For Service use. Min Historical Sensor value
n+123 SERVICE_MAX_TEMPERATURE R/W S FLT 4 N For Service Use. Max Historical temp.value
Expr. in TEMPERATURE_UNIT (idx n+28)
n+124 SERVICE_MIN_TEMPERATU/RE R/W S FLT 4 N For Service Use. Min Historical temp.value
n+125 SERVICE_MAX_STATIC_PRESSURE_VALUE R/W S F LT 4 N For Service Use. Max Historical Static Press Val Expr.in STATIC_P_SENSOR_UNIT (idx n+80)
n+126 SERVICE_MIN_STATIC_PRESSURE_VALUE R/W S FLT 4 N For Service Use. Min Historical Static Press Val n+127 RESET_SERVICE_MIN_MAX_VALUES W S U8 1 N
1 Reset Sensor Values
Historical Resets for Service2 Reset Static P Values
3 Reset Temp Values
VIEWS
n+134 VIEW_1 R 18 D
